SIPUXIN Automatic 4 Heads Tracking Gear Pump Filling Machine High Precision Cosmetic Essential Oil Shampoo Lotion Liquid Filler Production Line
spx-f-0701
Equipped with sanitary stainless steel gear pumps, the filling volume is precisely controlled by servo motor, applicable to various medium & high viscosity liquids: essential oil, lotion, shampoo, cream, cosmetic raw liquid, chemical detergent.
Quantity:
Description
Automatic 4 Heads Tracking Gear Pump Filling Machine High Precision Cosmetic Essential Oil Shampoo Lotion Liquid Filler Production Line
Machine composition: |
1. Servo tracking conveyor system 2. 4 sets sanitary SUS316L gear pump filling units 3. PLC touch screen control panel 4. Independent volume fine-tuning knob for each head 5. Anti-drip filling nozzles 6. Height adjustable filling frame 7. Photoelectric bottle induction sensor |
Usage and Application: |
Usage 1. Set target filling volume and conveyor speed on touch screen; 2. Bottles flow continuously on conveyor belt, filling heads track bottles to finish filling without stop; 3. Bottles automatically transfer to next packaging process after filling. Application Cosmetic lotion, essence, hair oil, shampoo, body wash, edible oil, industrial chemical medium-viscosity liquid filling. |
Core Advantages
1. Servo tracking filling, bottles move non-stop, higher output than static filling machines;
2. 4 independent gear pumps, each head adjustable separately, filling precision ±0.5%;
3. SUS316L pump body, corrosion resistant, easy disassembly for CIP cleaning;
4. Intelligent PLC control, parameter memory, quick switch between different bottle types;
5. Wide filling range, fit liquid from thin water to thick cream slurry;
6. Stable running, low failure rate, one-year full machine warranty.
| Item | Specification |
|---|---|
| Model | SPX-4T Gear Pump Filler |
| Filling Heads | 4 tracking filling heads |
| Pump Material | SUS316L stainless steel sanitary gear pump |
| Filling Precision | ±0.5% |
| Filling Range | 10–1000ml customizable |
| Control System | PLC + touch screen + servo tracking system |
| Automation Degree | Fully automatic |
| Drive Mode | Servo motor + gear pump drive |
| Production Capacity | 30–80 bottles/min (depends on bottle volume) |
| Power | 3.2KW |
| Body Material | SUS304 stainless steel frame |
