4-Head Servo Piston Liquid Filling Machine, Automatic Bottle Filler for Cosmetics, Food & Beverage

SPX-11GZ
Quantity:
Contact Now
add to cart
Product Description

4-Head Automatic Perfume Filling Production Line (Complete Set)
1. Production Line Overview
This fully automated perfume filling line integrates filling, pump assembly, cap screwing, mid-collar placement, and labeling into
one seamless system. It is designed for round glass perfume bottles (30-100mL) and supports spray pump or screw cap configurations
.
2. Technical Specifications
* Speed: 30-60 bottles/min (depends on bottle size)
* Filling Accuracy: ≤±0.5% of target volume
* Pump Compatibility: Standard 18/410, 20/410, etc.
* Power Supply: 220V/380V, 50Hz
* Materials: 304 stainless steel (contact parts)

3. Advantages
✅ End-to-End Automation – From empty bottles to finished labeled products
✅ Flexible Configuration – Adjustable for different bottle shapes (50-150mm height)
✅ High Precision – Servo-driven filling and labeling
✅ Easy Changeover – Quick-adjust mechanisms for bottle/pump sizes
Module
Function
Key Features
Bottle Unscrambler
Automatically feeds & aligns empty bottles
Vibration plate/starwheel sorting
4-Head Filling Machine
Precision liquid filling (perfume/alcohol-based)
Servo piston filler, accuracy ±0.5%
 Automatic Pump Feeder
Orients & installs spray pumps
Vibratory bowl + robotic placement
Capping Unit
Screws/compresses pump heads
Torque-controlled, adjustable for different pumps
Mid-Collar Assembly
Feeds & presses metal/plastic collars
Pneumatic pressing, force control
Round Bottle Labeler
Applies front/back labels (oval/round bottles)
Servo-driven, ±0.3mm precision
Conveyor System
Links all modules
Variable speed, stainless steel construction
Company Introduction
About Us
Guangzhou Sipuxin Light Industrial Machinery Equipment Co.,Ltd.with Yangzhou Sipuxin Light Industrial Machinery Equipment Factory as a solid backing,specializing in cosmetics,pharmaceutical,food,daily chemicals and other industries complete sets of equipmer manufacturers,to provide customers with a variety of special application fields of solutions .
The main products include vacuum homogenizing emulsifier,high-shear liquid detergent mixer,storage tank various cream,various bottle capping machine and other cosmetic and perfume whole-set production line,laboratory equipment,conveyor,etc.
