automatic perfume filling machine

Automatic rotary perfume filling crimping collaring machine

SPX -XSGZ
Quantity:
Contact Now
add to cart
Multi-Function Perfume Filling Capping Sealing Machine for Fragrance, Essential Oil & Cosmetic Spray Bottles.This machine integrates cleaning, filling and capping. Specifically designed for fully automated packaging of various perfume bottles, it is convenient to operate, time-saving and highly efficient.

Product Overview
SXS- Rotary Perfume Cleaning & Filling & Crimping & collaring & automatic to put bottles on conveyor & Automatic cap feeder Machine is used for filling perfume, floral water, and other water based materials. It is also equipped with a recycle system, after reaching set volume the overflowed liquid will be recycled inside the container, which saving time and labor tensity.
This automatic perfume filling machine adopts the automatic operation form, reduces the manual filling link, and has high precision and high automation compared with the traditional perfume filling process. At the same time, the equipment also use PLC control, which is simple and easy to operate.
Touch Screen Control PLC
Siemens Touch screen operation, simple and convenient operation.
2 Filling Nozzles
The parts in contact with materials are made of SUS 316 stainless steel. which meets GMP requirements. The filling volume andfilling speed can be adjusted arbitrarily, and the filling accuracy is high. The filling bulkhead adopts an anti-drip device.Level-controlled filling.

Air cleaning device
Fully Automatic Air cleaning 1. Material: SUS. 2. 2 heads 3. air pressure: 0.6-0.8Mpa 4.Height adjustable for different sizes ofbottles Function: blow off dust in the bottle, cleaning empty bottle
Crimping device
Fully automatic crimp the spray pump after vibration bowl auto loading spray pumps
Robot hand pick bottles out to conveyor
Automatic robot hand pick the bottles out to conveyor after finishing perfume press cover
Conveyor
1PCS*300mm conveyor belt-move bottle out
Filling hose
Hygienic food-grade hose connection from the perfume storage tank to the filling nozzle device
