Machine composition: |
This combined production set includes 5000L vacuum homogenizer emulsifier and matched 5000L heating mixing tank with lifting platform. All contact parts are SUS304 stainless steel mirror polished, with independent temperature control and vacuum emulsifying system, perfect for large-batch production of cream, lotion, shampoo, mask paste and body care products, fully comply with GMP cosmetic workshop standards. |
Usage and Application: |
1. Usage
①Pre-melt oil-phase and water-phase raw materials separately in the matched 5000L heating mixing tank, set and stabilize the required temperature via independent temperature control system.
②Transfer melted raw materials into the 5000L vacuum homogenizer pot through pipelines.
③Close the hydraulic lifting cover, turn on the vacuum pump to form a negative pressure environment inside the tank to avoid bubbles during emulsification.
④Start top frame stirring and bottom high-shear homogenizer simultaneously; adjust stirring speed and homogenizing speed according to product viscosity.
⑤Complete vacuum emulsification and homogenization cycle, then release vacuum, lift the pot cover, and discharge finished paste/liquid from the bottom outlet valve.
⑥Disassemble contact parts for cleaning and disinfection after each batch to prevent cross-contamination. 2. Application（适用行业与成品）
Applicable Industries
①Cosmetic & Personal Care Industry
②Daily Chemical Commodity Industry
③Fine Chemical Industry Applicable Final Products
Emulsions & Creams: Face cream, body cream, massage cream, foundation cream, ointment
Hair & Body Care: Shampoo, conditioner, body wash, hair mask, depilatory cream
Gels & Jelly Products: Aloe gel, massage gel, antibacterial hand gel, jelly mask
Liquid Serums & Toners: Essence liquid, facial toner, moisturizing lotion, spray raw liquid
Medical Ointments: Mild pharmaceutical emulsions, wound care ointment |
Core Advantages
1. Integrated combined designEquipped with matched 5000L heating mixing tank and lifting operation platform, realize oil-water phase separate pre-melting and vacuum emulsification in one whole production set, greatly improve production efficiency for large-batch manufacturing.
2. High-precision temperature & speed controlIndependent electric heating interlayer, temperature error controlled within ±1℃; PLC touch screen adjustable stirring and homogenizing speed, adapt to thin lotion and thick cream different viscosity raw materials.
3. Vacuum bubble-free emulsification systemBuilt-in vacuum pump to eliminate air bubbles during mixing, finished products present smooth, delicate texture without grain, meet high-end cosmetic quality standard.
4. Easy to operate & cleanHydraulic lifting cover design for convenient feeding, observation and full disassembly cleaning; quick-release structure on all material contact parts, comply with GMP hygiene requirement.
5. Energy saving & low noise operationInsulated jacket reduces heat loss and power consumption; imported servo motor and sealed bearing structure, stable running with low noise during long-hour continuous work.
6. Long service life & durable structureAll product contact parts adopt thickened SUS304 stainless steel with mirror polishing, anti-corrosion and wear-resistant; heavy-duty gearbox and transmission components extend equipment service life.
| Item | Specification |
|---|
| Model | SPX-5000L Vacuum Emulsifier Combined Set |
| Main Vacuum Emulsifier Volume | 5000L (effective working volume) |
| Matched Mixing Tank Volume | 5000L (water/oil phase preheating tank) |
| Material Contact Parts | SUS304 Stainless Steel, Mirror Polished |
| Heating Mode | Electric jacket heating with insulation layer |
| Temperature Range | Room Temperature ~ 95℃ |
| Temperature Control Accuracy | ±1℃ |
| Main Tank Stirring Type | Wall-scraping anchor agitator |
| Stirring Speed | 0-60 rpm (frequency conversion adjustable) |
| Stirring Motor Power | 5.5 kW |
| Homogenizer Type | Bottom high-shear homogenizer |
| Homogenizing Speed | 0-3000 rpm (frequency conversion adjustable) |
| Homogenizer Motor Power | 7.5 kW |
| Vacuum Degree | -0.08 ~ -0.095 MPa |
| Cover Lifting Mode | Hydraulic lifting |
| Control System | PLC touch screen intelligent control |
| Mixing Tank Stirring Power | 3.0 kW |
| Total Installed Power | 18.5 kW |
| Working Voltage | 380V / 50Hz / 3 Phase (customizable) |
| Lifting Platform | Stainless steel platform with guardrail & stairs |
| Overall Dimension | 6500×3500×4200 mm (L×W×H) |
| Net Weight | Approx. 2600 kg |
| Certification | CE, ISO 9001, GMP Compliant |
| Application | Cosmetic cream, lotion, shampoo, ointment, gel, body care products |
