vacuum emulsifier

1000L Fixed Vacuum Homogenizing Emulsifier Machine Cosmetic Cream Making Mixer for Lotion Ointment Shampoo Production

SPX-SGH
Quantity:
Contact Now
add to cart
Product Description

Performance
1.The homogenizing structure made through German technology adopts the inported double-end mechanical seal effect.The maximum emulsifying tatation speed can reach 4,200rpm and the highest shearing fineness can reach 0.2-5um.
2.The pot body is welded by imported three-layer stainless steel plate.The tank body and the pipes adopt mirror polishing,which fully confirms to GMP requirements.
3.According to technological requirements,the tank body can heat or cool the materials.The heating modes mainly include steam heating or electric heating.
Application1000L Fixed Vacuum Emulsifier is a professional vacuum homogenizer, this vacuum emulsifier is specially made as cosmetic vacuum emulsifier for cream and lotion making. This fixed vacuum emulsifier integrates stirring, homogenizing and vacuum deaeration, the vacuum homogenizer can process all kinds of cosmetic paste. As a mature cosmetic emulsifier, this vacuum emulsifier matches independent oil phase tank and water phase tank, the vacuum homogenizer is widely used in cosmetic factory as core emulsifier equipment..

Weight
About 2000kg
Product name
Liquid soap /cosmetic paste cream making machine
Heating way
Steam heating or Electric heating
Capacity
1500L
Function
Homogenizer and mixing, Heating, Emulsifier
Material
SUS304/316L
Advantage
Customized
Details Images
Botton control pannel
Central control panel controls all running parameters of vacuum emulsifier, adjust speed, temperature and vacuum degree of vacuum homogenizer, one panel controls the whole set of cosmetic emulsifier and its auxiliary pre-mix tanks.
Mixing system
the mixing system consists of inter fix paddle,scrapper mixer and clockwise direction blender,which the retation speed can reach 63 times per minute.and the perfect mixing result increase the mixing efficiency and performance,as well as heating efficiency.
Water Tank And Oil TankMatching pre-mix tanks support raw material preheating for vacuum emulsifier, shorten production cycle of vacuum homogenizer, greatly lift daily output of the fixed cosmetic emulsifier, improve working efficiency of vacuum emulsifier.
Top dispersion structure of vacuum emulsifier breaks agglomerated powder before homogenization of vacuum homogenizer, optimize raw material mixing effect of the fixed cosmetic emulsifier, upgrade finished product quality from this vacuum emulsifier
Operating Platform
motor
Use safe,non-slip oilproot and waterproot operating platform to protect the safety of workers. To ensure that workers have access to the tank for easy handling and dumping of materials.
