Vacuum emulsifier

Vacuum Emulsifying Machine Electric Heating High Speed Top Homogenizer for Food & Toothpaste Making

SGT
Quantity:
Contact Now
add to cart
Machine components details
Product name
Toothpaste and cosmetics making equipment
Capacity
500L/300L/customization
Material
Stainless steel sus304/sus316
Heating way
Power:18KW
Electric heating water in jacket with tap-water cooling system
Mixing way
Power: 4KW; Speed: 0-63 r/min
Mixer：Fixed stirrer & frame-wall teflon scrapping agitator with blade
Homogenizer way
Power: 7.5KW; Speed: 0-3000RPM,speed adjustable
Vacuum system
power: 3KW
Control way
Button control/PLC+Touch screen
MOQ
1 Set
Origin
Guangzhou/Yangzhou,China
Sale warranty
1 year
After sale service
24 hour online video technical  suppoert
Pictures for reference
Lid accessories
Sight glass:For better observation of the working situation inside.
Material inlet:Transfer the material through vacuum sunction.
Spice bucket:Add the fragrance and small additives.
Air breather:Prevent air from entering when vacuuming; Balance air pressure between pot and outer environment.
Clean device:Spray ball can 360 ° rotate to clean the pot.
Lamp:For better observation .
Vacuum pressure gauge:Set and display the pressure inside the pot.
Mixing system
Helical ribbon mixer with side Teflon scraper and disperser

Outer mixer speed:0-63RPM
Disperser speed:0-1440RPM,speed is adjustable, ABB Switzerland brand ,frequency converter.
Material:SUS.316
Effect:The mixer of the emulsifier achieves rapid dispersion and homogenization through directional shear force and circulating
flow, forming a stable and delicate emulsion, and at the same time, the structure is simple and the energy consumption is low,
which is suitable for the continuous emulsification of high viscosity materials.
Homogenizing system
High shear top homogenizer
Speed:0-3000RPM,speed is adjustble.ABB Switzerland brand ,frequency convertor.
Material:SUS.316
Component:It is made of stator and rotor.Rotor and stator adopts wire cutting finish machining, polishing treatment before assembly. Axis adopt dynamic balance process.homogenizer Adopting Germany Bergman mechanical seal, NSK bearing made in Japan.
Oil and water phase pot
Dispersing mixer:0-960 RPM
Material:SUS.316

Cover: Flip open cover

Function:Pre-heating and pre-mixing the raw material
Vacuum pump
Vacuum pump is generally water ring vacuum pump,it is equipped with stainless steel circulating water tank and control solenoid valve.
The maximum vacuum limit:0.1Mpa (generally 0.085Mpa)
Function:
1.Through vacuum, remove air and defoaming.
2.Transfer the raw material through vacuum suction
Bottom discharge
The bottom discharge hole with manual valve control.

4 ways of discharging:
1.Gravity discharge:It is suitable for the low viscous product.Let it be discharged by gravity
2.Pressure discharge:Add air,give it pressure to discharge the product.
3.Pump discharge:Use pump(like lobe pump) to discharge the product.
4.Tilting discharge:Use the tilting function to tilt the pot down,to discharge the product.
Button control box
Material:SUS.304
Components:Power switch,voltage,current,speed adjustment,temperature controller,timer of the homogenizer,self-protection system
etc.

* Be able to display, set and adjust the center mixer speed .
* Be able to set and adjust the homogenizing speed
* Be able to display, set and adjust temperature
* Be able to display,set and adjust working time for homogenizer.
Stair and operating platform,handrail
Material:SUS.304
2mmThickness:
Function：
1.It is water-proof and oil-proof,to prevent people from slipping.
2.It is very easy to clean and maintain it.
3.It provides a place for people to operate it.
Engineering Case
Package
FAQ
1.Are you a factory or trading company?We are a direct factory with over 24 years of production experience. We support factory inspection and welcome your visit anytime.2.Where is your factory? Our factory is located in Baiyun District, Guangzhou City, Guangdong Province. 3.Can your machines be customized?Yes. We provide OEM & ODM service. We can customize machine size, capacity, material, voltage and functions according to your production requirements.
4.What is your warranty period?We provide 1 year warranty for the whole machine and lifelong technical support and consoulation.
5.How do I do the installation of the machines? We will send you the user manuals and videos of the operating and installing of the machines.We can also provide the online technical support through the video call.
We can also arrange our engineers to your country to help installation and teaching.
